CUBE LINE C640

TYPE Undercounter warewasher
LINE CUBE LINE
BASKET 500x600
SIZE 585x715x865
CUBE LINE c640
UP
CUBE LINE c640
ADVANCE

Reliability and ease of use: these are the key words of the CUBE line. The UP control panel with buttons combines practicality and great durability. The simple and extremely efficient electronic card offers the possibility of setting and controlling the rinsing and draining times, the washing and rinsing temperatures and the relative Thermostops, crucial for ensuring excellent washing results. The ADVANCE panel (optional) is the real strength of the CUBE line thanks to its 4 washing cycles and one automatic drain cycle (with drain pump installed). On the control panel you can easily view the tank and boiler temperature, the messages of the Self-diagnosis system, the Scheduled Maintenance warning and the intelligent Start button, which changes colour to always display the dishwasher status very easily.

C640 is a compact warewasher, a real bonus in undercounter installations for restaurateurs who have to wash quite a few dishes (max 22/basket), baking trays and trays in a very tight space. In fact, thanks to the dedicated basket, you can wash GN 1/1 65 mm high baking trays, 600×400 dough trays and cake trays, while maintaining the measurements of a comfortable undercounter dishwasher. With its powerful wash pump and 30mmØ washing arms, removing stubborn dirt will not be a problem using a single 120-second standard cycle in the UP version with a maximum productivity of 30 baskets/hour (660 dishes/hour).

The standard double electric rinse-aid and detergent dispenser ensures maximum hygiene at each wash cycle with great savings: the moulded washing and rinsing arms ensure reliability and durability. The bodywork is made entirely of AISI 304 steel and has been designed with all of the components in the front for easy technical assistance. Sturdy and reliable dishwashers to best deal with every moment of your day.

DISHWASHERS FEATURES
Dimensions - (mm) L - P - H 585x715x865
Height glass max 340mm
Ø height plate max 370mm
Height pot max 340mm
Trays GN1/1 60x40
Tank heating element - Tank capacity 2,6kW - 30lt
Boiler heating element - Boiler capacity 5,4kW - 7,3lt
Washing pump 1,12kW / 1,5 Hp
Total power input / Current 6,52kW / 16A
Standard input voltage 400V3N+T 50Hz
Recommended inlet water temperature +55°C
Water hardness 7÷10 °f
Water consumption per cycle (inlet suggested pressure 2 BAR) 2,0lt
Adjustable detergent and rinse-aid dispenser ELECTRIC
STANDARD EQUIPMENT
Cutlery insert 2
Basket for trays 10/12 compartments 500x600x100mm 1
Basket for glasses dim.500x600x100mm 1
Basket for 22 dishes dim.500x600x100mm 1
OPTION
UNIKO touch display with IKLOUD Wi-Fi control -
Input voltage 230V/3+T
Booster pump kit 0,5Hp
Drain pump kit 40W
Boiler heating element 4,5kW
Boiler heating element 9kW
Thermo/acoustic insulation double wall kit and upper cover -
Reverse osmosis system -
Basket for trays with 4 compartments dim.500x500x200mm
Inclined basket for wine glasses dim.500x500x170mm
Kit 4 Stainless steel feet 50-70mm
ADVANCE display
= INSTALLABLE ACCESSORY , - = NOT INSTALLABLE ACCESSORY

C640

CUBE LINE c640
